| Air Cooled Condensing Unit |
| |
 |
| Features/Benefits |
-
-
-
-
-
- |
All models is housed in the our Class "1" cabinet with
small foot print advantages for reduced space
requirement.
Seacon weather cabinet, powder painted
& withstanding minimum 500 hours of salt spray test as
per ASTM B117.
Fully Hermetic reciprocating
compressor engineered for efficient and dependable operation.
Compressor with built-in thermal overload protector
against high current or temperature.
Separate insulated compressor compartment ensures
quiet operation.
Standard 230V controls (110V on requested).
Selected model include Flare liquid & suction service
valves to ensure fast and easy installation and servicing.
Direct driven propeller fan for horizontal air discharge.
Metal fan guard offers quick access and easy
maintenance with low noise characteristics. |
| |
|
|
|
| Capacity Range From: |
1 - 10 Tons |
For More Detail: |
Download |
|
| Model: GS-V-CU |
10 |
12 |
18 |
25 |
30 |
36 |
| Nominal Capacity Cooling |
|
 |
|
|
|
|
|
| BTUH |
10,000 |
12,000 |
18,000 |
24,000 |
30,710 |
35,830 |
| Tons |
0.83 |
1 |
2 |
2 |
3 |
3 |
| WATT |
2,928 |
3,514 |
5,271 |
7,027 |
9,000 |
10,500 |
| Nominal Capacity Heating |
BTUH |
10,000 |
13,000 |
19,000 |
27,000 |
31,000 |
37,000 |
| Tons |
1 |
1 |
2 |
2 |
3 |
3 |
| WATT |
2,928 |
3,514 |
5,271 |
7,027 |
9,000 |
10,500 |
Rated Air Flow At High
Speed |
CFM |
- |
- |
- |
- |
1,000 |
1,200 |
| CMH |
- |
- |
- |
- |
1,700 |
2,040 |
| Condensing Unit GS-V |
TYPE |
Horizontal Blow steel Cabinat Type |
| Compressor |
TYPE |
Rotory / Scroll / Reciprocate Type |
| Power Input |
WATT |
953 |
1,203 |
1,956 |
2,476 |
3,150 |
3,450 |
| Rated Current |
AMP |
4.2 |
6 |
9 |
11 |
14 |
16 |
| Power Supply |
V/P/Hz |
220V / 1P / 50 OR 60Hz |
| Condenser Fan |
TYPE |
Propeller Fan “Plastic“ |
| QTY. |
1 |
| Motor 1 speed |
| Power |
WATT |
33 |
57 |
193 |
| Current |
AMP |
0.35 |
0.5 |
0.89 |
| Power Supply |
V/P/Hz |
220V / 1P / 50 - 60Hz |
| Condenser Coil |
TYPE |
Aluminium Louver Slit Fin With Innergroove Tube (Copper Fin On Requset Only) |
| Connection |
TYPE |
Sweat Type |
| Suction Line |
TYPE |
1/2 |
5/8 |
3/4 |
| Liquid Line |
TYPE |
3/8 |
3/8 |
3/8 |
| Refrigerant (Holding Charge) |
TYPE |
R-22 (R-407C On Requset Only) |
| Weight |
KGS. |
44 |
48 |
64 |
75 |
88 |
92 |
|
| |
|
|
|
|
| Condensing Unit Model: GS-V-CU |
363 |
44 |
50 |
60 |
80 |
120 |
| Nominal Capacity Cooling |
|
|
|
|
|
|
|
| BTUH |
34,800 |
43,000 |
50,000 |
60,000 |
80,000 |
120,000 |
| Tons |
3 |
4 |
4 |
5 |
6.67 |
10 |
| WATT |
10,200 |
12,602 |
14,700 |
17,600 |
23,400 |
35,200 |
| Nominal Capacity Heating |
BTUH |
37,000 |
47,000 |
52,000 |
64,000 |
- |
- |
| Tons |
3 |
4 |
4 |
5 |
- |
- |
| WATT |
10,200 |
13,774 |
14,700 |
17,600 |
- |
- |
| Rated Air Flow At High Speed |
CFM |
1,200 |
1,400 |
1,600 |
2,000 |
3,000 |
4,000 |
| CMH |
2,040 |
2,379 |
2,720 |
3,400 |
5,100 |
6,800 |
| Condensing Unit GS-V |
TYPE |
Horizontal Blow steel Cabinat Type |
| Compressor |
TYPE |
Rotory / Scroll / Reciprocate Type |
| Power Input |
WATT |
3,110 |
4,080 |
4,430 |
5180 |
3430 x 2 |
5180 x 2 |
| Rated Current |
AMP |
6 |
6 |
8 |
8.9 |
6.3 x 2 |
8.9 x 2 |
| Power Supply |
V/P/Hz |
380-440V / 3P / 50 OR 60Hz |
| Condenser Fan |
TYPE |
Propeller Fan “Plastic“ |
| QTY. |
1 |
2 |
4 |
| Motor 1 speed |
Power |
193 |
193 |
193 x 2 |
193 x 2 |
193 x 4 |
193 x 4 |
|
Current |
0.89 |
0.89 |
0.89 x 2 |
0.89 x 2 |
0.89 x 4 |
0.89 x 4 |
| Power Supply |
V/P/Hz |
220V / 1P / 50/60Hz |
380-440V / 3P / 50 OR 60Hz |
| Condenser Coil |
TYPE |
Aluminium Louver Slit Fin With Innergroove Tube (Copper Fin On Requset Only) |
| Connection |
|
Sweat Type |
| Suction Line |
|
3/4 |
7/8 |
7/8 |
7/8 |
1-1/8 |
1-3/8 |
| Liquid Line |
|
3/8 |
1/2 |
1/2 |
1/2 |
3/4 |
7/8 |
| Refrigerant (Holding Charge) |
TYPE |
R-22 (R-407C On Requset Only) |
| Weight |
KGS. |
92 |
100 |
110 |
120 |
200 |
240 |
|
|
