| Air Cooled Condensing Unit |
| |
 |
| Features/Benefits |
| - |
The PNSA-C-CU unit has a compact design that is up to
30% smaller than earlier air-cooled chillers. The
compact footprint can yield substantial installation
savings by requiring less structural steel, concrete,
security fencing or architectural screening. The
PNSA-C-CU unit is delivered as a complete package
for easy installation.
A quick start-up is assured once
installation is complete,
since each PNSA-C-CU unit is manufactured at an ISO
9002 listed manufacturing facility to ensure quality In
addition, all units are factory run tested under full load
to provide reliable start-up. |
| |
|
|
|
| Capacity Range From: |
6.7 - 12.8 Tons |
For More Detail: |
Download |
|
| MODEL: PNSA-C-CU |
07 |
09 |
10 |
12 |
15 |
| Nominal Cooling Capacity |
|
 |
|
|
|
|
| BTUH |
80,000 |
90,700 |
100,000 |
120,000 |
150,000 |
| Tons |
6.67 |
7.56 |
9.58 |
10.38 |
12.83 |
| KWH |
23.4 |
26.6 |
33.7 |
36.5 |
45.1 |
| Power Input |
KW |
7.39 |
8.67 |
9.81 |
12.27 |
15.1 |
| Rated Voltage |
380V / 3P / 50Hz - 440V / 3P / 60Hz |
| Compressor Type |
Hermetic Scroll x 1 |
| Condenser Coil |
Type/Material |
Aluminium / Copper Corrugated Fin With Inner Groove Copper Tube |
| Rows..Fins/In |
2....16 |
3....14 |
2....16 |
3....12 |
| Tube Size (in) |
3/8 |
| Condenser Fan |
Type |
Propeller Fan : Vertical / Horizontal Discharge : Direct drive |
| Rpm. |
900 |
| Qty./Unit |
1 |
| MOTOR (H.P.) |
3/4 |
1 |
| Refrigerant |
Type |
R-22 (R-407C OR R-410A ON REQUEST ONLY) |
| Charge |
Holding (2 KG) |
| Connections |
| Suction |
(in.) |
1-1/8 |
1-3/8 |
1-5/8 |
| Liquid |
(in.) |
5/8 |
| Weight Operation |
(Kgs.) |
155 |
163 |
168 |
200 |
235 |
| Compressor |
| Voltage / Phase / Hz |
380V / 3P / 50Hz - 440V / 3P / 60Hz |
| Qty. |
1 |
| Power Input |
(KW) |
6,542 |
7,821 |
8,957 |
10,800 |
13,622 |
| FLA. |
(Amp.) |
12.1 |
14.3 |
20.7 |
22.9 |
27.3 |
| LRA. |
(Amp.) |
98 |
130 |
145 |
175 |
| Fan Motor |
| Voltage / Phase / Hz |
380V / 3P / 50Hz - 440V / 3P / 60Hz |
| Qty. |
1 |
| Power Input |
(KW) |
850 |
1,470 |
| FLA. |
(Amp.) |
1.2 |
1.23 |
|
|
